Microchip Technology HV5812PJ-G High Voltage Serial to Parallel Converter

The HV5812PJ-G is a state-of-the-art high voltage, serial to parallel converter from Microchip Technology. Designed to interface between low voltage digital logic and high voltage outputs, this robust integrated circuit is ideal for driving a wide array of devices, such as vacuum fluorescent displays (VFDs), light-emitting diodes (LEDs), and other applications requiring high voltage switching.

Key Features

• Output Voltage: The HV5812PJ-G can handle output voltages up to 80V, making it perfectly suited for high voltage applications.
• Output Channels: It features 20 output channels, each capable of sourcing 60mA, providing ample capacity for driving multiple components simultaneously.
• Serial Interface: The device is equipped with a serial input control, which simplifies the connection to microcontrollers and reduces the number of required I/O pins.
• CMOS Technology: Leveraging advanced CMOS technology, the HV5812PJ-G offers low power dissipation, which enhances the overall efficiency of the system.
• Enhanced Durability: It is designed with built-in clamp diodes for inductive transient suppression, which increases the reliability and longevity of the device.
• Package: The HV5812PJ-G comes in a 28-lead plastic DIP package, making it easy to integrate into a wide range of electronic assemblies.

Applications

The versatility of the HV5812PJ-G allows it to be used in various high voltage driving applications. It is particularly well-suited for driving VFDs, which are commonly found in consumer electronics, automotive displays, and industrial control panels. Additionally, its capability to drive LEDs makes it a valuable component in lighting systems and decorative applications that require high voltage for illumination.

Quality and Reliability

As with all Microchip products, the HV5812PJ-G is manufactured to the highest quality standards. It undergoes rigorous testing to ensure performance and reliability, providing engineers and designers with confidence in their high voltage applications. The device is also RoHS compliant, adhering to environmental standards for hazardous substances.
