Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr MDD
Series SMC
Package Tape & Reel
Product Status Active
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 40 V
Current - Average Rectified (Io) 3A
Voltage - Forward (Vf) (Max) @ If 550 mV @ 3 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 500 µA @ 40 V
Capacitance @ Vr, F 450pF @ 4V, 1MHz
Mounting Type Surface Mount
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 676356-SS34C
Ultra Librarian 3D Model Ultra Librarian SS34C CAD Model

Description

The SS34C is a fast recovery Schottky diode designed for rectification and switching applications in electronic circuits.

  • It: features a voltage rating of 40V and an average rectified current of 3A.
  • The: forward voltage drop @ 3A is 550mV, and the reverse leakage current @ the maximum reverse voltage is 500µA.
  • With: a capacitance of 450pF @ 4V and 1MHz, this diode is suitable for high-frequency applications.
  • The: SS34C is packaged in a surface mount SMC package, which is compatible with tape and reel packaging for easy handling and assembly.
  • It: is an active product in the MDD series and is unaffected by REACH regulations.
  • With: its fast recovery speed and high current rating, the SS34C is a reliable choice for rectification and switching in various electronic devices.
