Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 30 Weeks
Features Hot Swap Controller 1 Channel General Purpose
Manufacturer Maxim Integrated
Package Tube
Operating Temperature Range -40°C ~ 85°C
Mounting Surface Mount
Package 16-LSSOP (0.154", 3.90mm Width) Exposed Pad
Family Name MAX5926
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.31.0001
Quantity per package 100
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 882097-MAX5926EEE+
Ultra Librarian 3D Model Ultra Librarian MAX5926EEE+ CAD Model

Description

The MAX5926EEE+ from Maxim Integrated is a state-of-the-art hot swap controller designed to provide safe insertion and removal of circuit boards into live backplanes or other hot systems. This component is ideal for network servers, telecom equipment, and central office switching gear where system maintenance or expansion must occur without disrupting the power supply or data flow.

Key Features

  • Integrated Power MOSFET: The device includes an internal power MOSFET, which simplifies the design process by reducing external component count.
  • Programmable Current Limit: Users can set the current limit threshold to match the requirements of specific applications, ensuring protection against overcurrent conditions.
  • Adjustable Overcurrent and Overvoltage Protection: These features safeguard the system against potentially damaging conditions.
  • Undervoltage Lockout (UVLO): The UVLO feature ensures that the device operates only when the supply voltage is within an acceptable range, preventing malfunction due to low voltage.
  • Thermal Shutdown: The MAX5926EEE+ is equipped with a thermal shutdown mechanism that protects against overheating.
  • High Accuracy: This device provides high accuracy in current-sensing and fault protection, enhancing system reliability.

Applications

The MAX5926EEE+ is versatile and can be used in a variety of applications that require hot swap capabilities. It is particularly suitable for:

  • Server and Storage Systems
  • Redundant Power Supplies
  • Network Routers and Switches
  • Base Stations

Product Specifications

The MAX5926EEE+ operates over a wide voltage range and comes in a compact 16-pin QSOP package. Its specifications include:

  • Supply Voltage Range: 9V to 80V
  • Operating Temperature Range: -40°C to +85°C
  • Package Type: 16-QSOP

With its robust feature set, the MAX5926EEE+ by Maxim Integrated is an excellent choice for designers looking to implement hot swap functionality with high reliability and protection in their systems.
