Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Maxim Integrated
Packaging Tube
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 1/1
Duplex Full
Receiver Hysteresis 500mV
Data Rate 1Mbps
Operating Supply Voltage 3 V ~ 5.5 V
Operating Temperature Range 0°C ~ 70°C
Mounting SMD
Package 16-TSSOP (0.173", 4.40mm Width)
Manufacturer Package 16-TSSOP
Win Source Part Number 785898-MAX3227ECUE+
Popularity Medium
Supply and Demand Status Limited
Family Name MAX3227E
Introduction Date January 01, 1998
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian MAX3227ECUE+ CAD Model

Description

MAX3227ECUE+ RS-232 Transceiver by Maxim Integrated

The MAX3227ECUE+ from Maxim Integrated is a high-quality RS-232 transceiver designed to facilitate serial communication in a variety of applications. This device is particularly ideal for portable or space-constrained applications due to its low-power consumption and small footprint.

Key Features

  • Integrated Features: The MAX3227ECUE+ integrates a slew-rate-limited transceiver which minimizes EMI and reduces reflections caused by improperly terminated cables, ensuring reliable data transmission.
  • Low Power Consumption: Operating in a low-power shutdown mode, this transceiver significantly conserves power, making it suitable for battery-powered devices.
  • Flexible Logic Voltage: It operates with a 3.0V to 5.5V logic supply voltage, providing design flexibility and compatibility with a range of microcontrollers and digital interfaces.
  • AutoShutdown Plus™: The device includes AutoShutdown Plus™ feature that automatically enters a low-power state when the RS-232 cable is disconnected or the connected peripherals are turned off, further reducing power consumption.
  • High Data Rate: The transceiver supports data rates up to 250kbps, making it suitable for applications requiring moderate speed serial data communication.
  • Electrostatic Discharge Protection: With ±15kV ESD protection on transmitter outputs and receiver inputs, the MAX3227ECUE+ is robust against electrostatic discharges, enhancing system reliability.

Applications

The versatility of the MAX3227ECUE+ allows it to be used in a wide array of applications, including but not limited to:

  • Portable and battery-powered devices
  • Notebooks, laptops, and PDAs
  • Peripherals
  • Data cable interfaces
  • Industrial and medical equipment

Package and Quality

Encased in a 16-pin TSSOP package, the MAX3227ECUE+ is designed to meet the space requirements of compact systems without compromising on performance. Maxim Integrated ensures high standards of quality and reliability for this transceiver, making it a trusted choice for your serial communication needs.
