Maxim Integrated MAX3078EESA+ RS-485/RS-422 Transceiver

The MAX3078EESA+ from Maxim Integrated is a high-performance, half-duplex transceiver that is designed for RS-485 and RS-422 communication applications. It is capable of achieving data rates up to 250kbps while maintaining RS-485 and RS-422 standards compliance. This transceiver is an ideal choice for industrial, network, and automation systems where reliable data transmission is crucial.

Key Features

• High-Speed Operation: Supports data rates up to 250kbps, making it suitable for a variety of high-speed communication tasks.
• Extended Temperature Range: Operates over a wide temperature range from -40°C to +85°C, ensuring reliability in harsh environments.
• Low Power Consumption: Features a low-current shutdown mode and low quiescent current, which helps to reduce power consumption and extend battery life in portable applications.
• Robust Protection: Equipped with integrated protection against electrostatic discharge (ESD) up to ±15kV (Human Body Model), providing enhanced durability and reliability.
• Fail-Safe Receiver: The fail-safe receiver ensures a logic-high receiver output when the input is open or shorted, which enhances the safety of the communication system.

Applications

The MAX3078EESA+ is versatile and can be used in a variety of applications, including:

• Industrial Control Systems
• Building Automation
• Network Equipment
• Security Systems

Package and Availability

The device is available in a space-saving 8-pin NSOIC package, making it convenient for use in applications where board space is at a premium. The MAX3078EESA+ is also part of Maxim Integrated's commitment to providing long-term availability for industrial-grade components, ensuring support and supply continuity for system designers.

Ordering Information

To order or obtain more information about the MAX3078EESA+ RS-485/RS-422 transceiver, please visit Maxim Integrated's official website or contact an authorized distributor. Ensure to refer to the part number MAX3078EESA+ when making an inquiry or placing an order.
