Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Tube/Rail
Status Active
Type Transceiver
Protocol CAN
Number of Drivers/Receivers 1/1
Duplex Full
Receiver Hysteresis 100mV
Data Rate 1Mbps
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 1067185-MAX3059ASA+
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Communications & Networking, Consumer Electronics, Industrial
Ultra Librarian 3D Model Ultra Librarian MAX3059ASA+ CAD Model

Description

Maxim Integrated's MAX3059ASA+ Product Overview

The MAX3059ASA+ from Maxim Integrated is a robust, high-speed transceiver module designed for Controller Area Network (CAN) communication in automotive and industrial applications. This device is engineered to provide differential transmit and receive capability to the CAN protocol controller, enabling the reliable transmission and reception of data over a CAN network.

Key Features

  • High-Speed CAN Interface: Supports CAN protocol specification 2.0 part A and B, ensuring compatibility with high-speed CAN systems up to 1 Mbps.
  • Extended Temperature Range: Operates effectively over a wide temperature range from -40°C to +125°C, making it suitable for harsh environments.
  • Integrated Protection: Features protection against high-voltage transients, loss of ground, and overvoltage, enhancing the reliability and longevity of the device.
  • Low Power Consumption: Includes a low-current standby mode, which significantly reduces power consumption when the CAN network is inactive.
  • Robust ESD Protection: Offers ±15kV Human Body Model (HBM) ESD protection on the CANH and CANL bus pins, safeguarding against electrostatic discharge events.

Applications

  • Automotive Networks
  • Industrial Control Systems
  • Building Automation
  • Medical Equipment
  • Heavy Machinery

The MAX3059ASA+ is housed in a compact 8-pin SOIC package, which is ideal for space-constrained applications. Its integrated slope control provides reduced radio frequency interference (RFI), which is crucial for applications that require minimal electromagnetic emissions. The device also includes a dominant time-out function to prevent bus lock-up due to faulty controllers, further enhancing its robustness in a networked environment.

With its combination of high-speed communication, wide operating temperature range, and advanced protection features, the MAX3059ASA+ transceiver is an excellent choice for designers looking to implement reliable CAN networking in their automotive or industrial projects.

Maxim Integrated's commitment to quality and performance is reflected in the MAX3059ASA+, making it a trusted component for any CAN-based communication system.
