Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Texas Instruments
Packaging Reel - TR
Type Simple Reset/Power-On Reset
Number of Voltages Monitored 1
Output Push-Pull, Totem Pole
Reset Active Low
Reset Timeout 100 ms Minimum
Voltage - Threshold 2.93V
Operating Temperature Range -40°C ~ 85°C (TA)
Mounting SMD
Package SC-74A, SOT-753
Manufacturer Package SOT-23-5
Win Source Part Number 1272423-TPS3836K33DBVT
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Application Field Used in LED Lighting, Imaging, Video & Vision, Consumer Electronics, Automotive, Commercial
Family Name TPS3836
Introduction Date November 01, 2008
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian TPS3836K33DBVT CAD Model

Description

Product Overview: TPS3836K33DBVT

The TPS3836K33DBVT is a state-of-the-art supervisory circuit designed by Texas Instruments to provide precise voltage monitoring, primarily for microprocessors and other voltage-sensitive components. This device is engineered to ensure systems operate within their intended voltage ranges, thus safeguarding them from potential damage caused by voltage fluctuations.

Key Features

  • Voltage Threshold: The TPS3836K33DBVT has a preset threshold voltage of 3.3V, which is ideal for most standard logic levels and power supplies in common use.
  • Low Power Consumption: This device is optimized for low-power applications, consuming a quiescent current of only 9 µA, making it suitable for battery-powered and energy-efficient systems.
  • High Accuracy: It offers a high accuracy of ±2% over the full temperature range, which is crucial for reliable operation in various environmental conditions.
  • Reset Timeout: It features a programmable reset timeout period, providing design flexibility and ensuring proper system reset.
  • Small Footprint: The TPS3836K33DBVT comes in a compact SOT-23-5 package, which is space-efficient and ideal for space-constrained applications.
  • Temperature Range: It operates over a wide temperature range of -40°C to +85°C, accommodating a broad spectrum of industrial and commercial applications.

Applications

This supervisory circuit is versatile and can be used in various applications, including:

  • Portable/Battery-Powered Equipment
  • Desktop and Notebook Computers
  • Microprocessor/Microcontroller Systems
  • Data Storage Equipment
  • Industrial Control Systems
  • Communication Devices

Reliability and Quality

The TPS3836K33DBVT is built to meet the high standards of Texas Instruments' quality and reliability. With its precision voltage monitoring and low power consumption, it is an excellent choice for designers looking to incorporate a robust power management solution into their systems.
