Maxim Integrated MAX297MJA: High-Performance, 8th-Order, Lowpass, Elliptic, Switched-Capacitor Filters

The MAX297MJA from Maxim Integrated is a precision, 8th-order, lowpass, elliptic, switched-capacitor filter that significantly eases the design of high-performance signal processing circuits. This integrated circuit is designed to provide a sharp cutoff frequency characteristic, making it an ideal choice for applications requiring a stringent selection between signal and noise frequencies.

Encased in a durable CERDIP-8 package, the MAX297MJA is engineered to operate over a wide temperature range, ensuring reliability and consistent performance in various environments. The device boasts a user-selectable cutoff frequency that can be set by an external clock or can be controlled by an onboard oscillator, which is resistor-tunable for added flexibility in design.

One of the remarkable features of the MAX297MJA is its low noise and low distortion characteristics, which make it suitable for high-fidelity audio applications and precision data acquisition systems. The filter's 8th-order elliptic response provides a steep roll-off beyond the cutoff frequency, ensuring excellent rejection of unwanted frequencies with minimal signal loss within the passband.

The MAX297MJA also features a fully differential signal path, which enhances the common-mode rejection ratio (CMRR) and reduces the influence of noise and interference on the signal integrity. This differential design is particularly beneficial for applications that are sensitive to noise or require long signal runs, such as professional audio equipment, instrumentation, and telecommunication systems.

For designers concerned with power consumption, the MAX297MJA operates with a single +5V supply, minimizing power requirements while maintaining high performance. Additionally, the device includes a shutdown mode that reduces power consumption further when the filter is not in active use.

In summary, the MAX297MJA from Maxim Integrated is a versatile, high-quality, lowpass filter that offers a blend of performance, flexibility, and ease of use for designers working on sophisticated signal processing applications. Its robust feature set ensures that it can meet the stringent requirements of a wide range of industries, from audio and video to telecommunications and medical electronics.
