Maxim Integrated MAX232CSE+T RS-232 Interface IC

The MAX232CSE+T from Maxim Integrated is a highly-reliable RS-232 interface IC designed to translate signals between serial communication ports and a microcontroller or computer. This particular model is a dual driver/receiver that includes a capacitive voltage generator to supply RS-232 voltage levels from a single 5V supply. Each receiver converts RS-232 inputs to 5V TTL/CMOS levels, and the drivers convert 5V TTL/CMOS levels to RS-232 levels, making it an essential component for applications that require serial communication.

Key features of the MAX232CSE+T include:

• Meets or Exceeds TIA/EIA-232-F and ITU Recommendation V.28
• Operates from a Single 5V Power Supply with 1.0µF Charge-Pump Capacitors
• Operates up to 120kbps
• Two Drivers and Two Receivers
• ±30V Input Levels
• Low Supply Current... typically 8mA
• ESD Protection for RS-232 I/O Pins to ±15kV (IEC 1000-4-2 Air Gap and ±8kV IEC 1000-4-2 Contact Discharge)

The MAX232CSE+T is commonly used in applications that require a connection to RS-232 serial ports such as GPS units, barcode scanners, and other data communication devices. Its robust ESD protection makes it suitable for use in environments where electrostatic discharge could pose a risk to electronic components.

This IC is provided in a 16-pin narrow SO package, which is surface-mountable and suitable for automated assembly processes. The MAX232CSE+T is also lead-free and RoHS compliant, making it an environmentally friendly choice for manufacturers and designers who are conscious of their environmental impact.

With its reliability and comprehensive features, the MAX232CSE+T is a go-to solution for designers looking to establish RS-232 communications with the assurance of Maxim Integrated's quality and performance. Whether it's for industrial control systems, point-of-sale terminals, or networking equipment, this IC delivers consistent and efficient performance, ensuring smooth and stable serial data exchanges.
