Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Maxim Integrated
Packaging Tube
Technology Internal Switch
Number of Circuits 1
Applications General
Mounting SMD
Package 14-TSSOP (0.173", 4.40mm Width) Exposed Pad
Manufacturer Package 14-TSSOP-EP
Voltage - Working 36V
Win Source Part Number 701381-MAX14571EUD+
Series MAX series
Popularity Medium
Supply and Demand Status Limited
ECCN EAR99
Country of Origin Philippines, Thailand
Halogen Free Compliant
Estimated EOL Date 2019
Ultra Librarian 3D Model Ultra Librarian MAX14571EUD+ CAD Model

Description

The MAX14571EUD+ from Maxim Integrated is a sophisticated overvoltage protection controller designed to safeguard low-voltage systems against damaging high-voltage conditions. This compact, integrated circuit is ideal for a variety of applications, including USB ports, portable electronics, and industrial control systems, where maintaining voltage integrity is crucial.

Key Features

  • Adjustable Overvoltage Protection: The device allows users to set the overvoltage protection threshold according to their specific requirements, ensuring tailored protection for sensitive electronics.
  • Low Quiescent Current: With its energy-efficient design, the MAX14571EUD+ consumes minimal power when idle, making it suitable for battery-powered applications.
  • Wide Operating Voltage Range: This controller operates effectively across a broad voltage range, accommodating various power supply standards and ensuring versatility across different platforms.
  • Fast Response Time: In the event of an overvoltage condition, the device reacts swiftly to disconnect the load, minimizing the potential for damage.
  • Integrated MOSFET: The inclusion of an internal MOSFET simplifies the circuit design and reduces the need for external components, saving space and cost.

Applications

  • USB Ports and Hubs
  • Portable Electronic Devices
  • Industrial Control Systems
  • Set-Top Boxes
  • Notebook Computers

Product Specifications

The MAX14571EUD+ is housed in a TSSOP-14 package, offering a compact solution for space-constrained designs. It operates over a temperature range of -40°C to +125°C, ensuring reliable performance in a wide array of environments. The device also features an automatic retry function, which attempts to reconnect the load after a fault condition has been cleared, thus reducing system downtime.

For engineers and designers looking for a robust overvoltage protection solution, the MAX14571EUD+ provides a combination of precision, flexibility, and reliability. Its comprehensive feature set and straightforward implementation make it an excellent choice for safeguarding critical electronic systems from unexpected voltage spikes.
