The M/A-Com Technology Solutions CMM6004-SC is a high-performance GaAs MMIC driver amplifier, closely related to the CMM6004, but potentially offered in a slightly different package or with enhanced screening/testing. It serves as a driver amplifier for applications demanding high gain and output power. Its robust design ensures reliability in harsh conditions.

Applications

• Point-to-point radio links: Functions as a driver amplifier within microwave radio systems employed in telecommunications networks.
• VSAT (Very Small Aperture Terminal): Boosts signal strength in satellite communication terminal equipment.
• Military communications: Integrated into military-grade radio and communication systems.
• Test and measurement equipment: Deployed within signal generators and spectrum analyzers to amplify signals.

Features

• High Gain: Usually delivers a gain of approximately 20 dB, amplifying input signals significantly.
• High Output Power: Capable of producing a P1dB (output power at 1 dB gain compression) around 20 dBm.
• Broadband Performance: Operates effectively across a wide frequency band, generally from 6 to 18 GHz.
• Single Positive Supply: Requires a single positive voltage source for power, simplifying design.
• Small Size: Its compact MMIC construction allows for seamless integration into small devices.

Benefits

• Improved System Performance: The amplifier's considerable gain and power output enhance the overall efficiency of communications equipment.
• Simplified System Design: The requirement for only a single power supply rail reduces the complexity of power circuitry.
• Enhanced Reliability: GaAs MMIC fabrication results in a device that is rugged and maintains long-term reliability.
• Cost-Effectiveness: Provides an economical solution for driver amplification needs.
• Easier Integration: Due to its small size and straightforward electrical interface, the CMM6004-SC integrates easily.

Additional Details

The CMM6004-SC comes in a surface-mount package, facilitating efficient assembly on printed circuit boards. Impedance matching should be implemented for peak performance. Performance parameters are generally specified at a case temperature of 25°C. Adequate thermal management is vital for reliable operation over its lifespan.

Typical Specifications:

• Frequency Range: 6-18 GHz
• Gain: 20 dB (typical)
• P1dB: 20 dBm (typical)
• Supply Voltage: +5V to +8V
• Package Type: Surface Mount
