Category Discrete Semiconductor Products - Thyristors - SCRs
Mfr Littelfuse Inc.
Package Bulk
Product Status Discontinued
Voltage - Off State 800 V
Voltage - Gate Trigger (Vgt) (Max) 1.5 V
Current - Gate Trigger (Igt) (Max) 30 mA
Voltage - On State (Vtm) (Max) 1.6 V
Current - On State (It (AV)) (Max) 12.8 A
Current - On State (It (RMS)) (Max) 20 A
Current - Hold (Ih) (Max) 40 mA
Current - Off State (Max) 20 µA
Current - Non Rep. Surge 50, 60Hz (Itsm) 255A, 300A
SCR Type Standard Recovery
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Through Hole
Package / Case TO-220-3 Isolated Tab
Supplier Device Package TO-220 Isolated Tab
Standard Package 500 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.30.0080
California Prop 65 Warning Information
Win Source Part Number 662941-S8020L
Ultra Librarian 3D Model Ultra Librarian S8020L CAD Model

Description

The 662941-S8020L is a standard recovery SCR (silicon-controlled rectifier) component from Littelfuse Inc.

  • Package: Bulk package
  • Standard Package Quantity: 500 pieces
  • Maximum Current Hold (Ih): 40mA
  • Off-State Voltage: 800V
  • Gate Trigger Voltage (Vgt): 1.5V
  • Gate Trigger Current (Igt): 30mA
  • Maximum On-State Voltage (Vtm): 1.6V
  • Average On-State Current (It (AV)): 12.8A
  • Maximum RMS On-State Current (It (RMS)): 20A
  • Maximum Off-State Current: 20µA
  • Non-Repetitive Surge Current (50Hz): 255A
  • Non-Repetitive Surge Current (60Hz): 300A
  • Mounting Type: Through-Hole
  • Package/Case: TO-220-3 Isolated Tab
  • Status: Discontinued and is no longer in active production.
