Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Hot Swap Controller
Number of Channels 1
Internal Switch(s) Yes
Applications General Purpose
Features Auto Retry, UVLO
Programmable Features Current Limit
Supply Voltage - Operating 2.5 V to 6.5 V
Current - Output (Max) 2.5A
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 6-SON (2x2)
Feature Pins /Fault, ILIM
Win Source Part Number 033748-TPS25200DRVR
Family Name TPS25200
Introduction Date April 17, 2013
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TPS25200DRVR CAD Model

Description

Product Overview: TPS25200DRVR from Texas Instruments

The TPS25200DRVR is a high-performance, compact, overvoltage protection device designed by Texas Instruments to safeguard low-voltage systems against voltage transients and surges. This advanced circuit protection solution is ideal for a variety of applications, including consumer electronics, data communication systems, and industrial equipment.

Key Features

  • Voltage Protection: Provides robust protection against overvoltage events, ensuring the safety and longevity of downstream components.
  • Adjustable Overvoltage Lockout (OVLO): Users can set the OVLO threshold to meet specific application requirements, enhancing flexibility and customization.
  • Fast Response Time: The device reacts swiftly to overvoltage conditions, minimizing the risk of damage to sensitive electronics.
  • Low R<sub>DS(on): Features a low on-resistance FET that reduces power loss and improves efficiency during normal operation.
  • Wide Operating Range: Supports an input voltage range suitable for various low-voltage applications, making it a versatile choice for designers.
  • Thermal Shutdown: Includes a thermal shutdown feature that protects the device and the system from overheating.
  • Compact Package: The TPS25200DRVR comes in a small 6-pin SON package, which is ideal for space-constrained applications.

Applications

The TPS25200DRVR's versatile nature makes it suitable for a wide array of applications, including:

  • Portable Electronics
  • USB-Powered Gadgets
  • Power Supplies
  • Networking Equipment
  • Industrial Control Systems

Technical Specifications

Some of the key technical specifications of the TPS25200DRVR include:

  • Input Voltage Range: 4.5V to 18V
  • Adjustable OVLO Threshold
  • Low R<sub>DS(on) for High Efficiency
  • Operating Temperature Range: -40°C to 125°C

For engineers and designers looking for a reliable overvoltage protection solution, the TPS25200DRVR from Texas Instruments offers a blend of performance, flexibility, and compactness, making it an excellent choice for protecting sensitive electronic systems.
