NANOSMDC012F-2 Littelfuse Inc. NANOSMDC012F-2 real image
Same model may have multiple batches, images only for reference.
NANOSMDC012F-2 Littelfuse Inc. NANOSMDC012F-2 real image
NANOSMDC012F-2 Littelfuse Inc. NANOSMDC012F-2 real image
Same model may have multiple batches, images only for reference.

NANOSMDC012F-2

Part No NANOSMDC012F-2
Manufacturer Littelfuse Inc.
Catalog PTC Resettable Fuses
Description PTC Resettable Fuse 0.12A(hold) 0.39A(trip) 48VDC 10A 0.5W 0.2s 1.4Ohm SMD Solder Pad 1206 T/R Automotive / POLYSWITCH 0.125A RESET FUSE SMD
Datasheet
NANOSMDC012F-2 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Littelfuse Inc.
Packaging Reel - TR
Status Active
Type Polymeric
Voltage - Max 48V
Current - Max 10A
Current - Hold (Ih) (Max) 120mA
Current - Trip (It) 390mA
Time to Trip 200ms
Resistance - Initial (Ri) (Min) 1.4 Ohm
Resistance - Post Trip (R1) (Max) 6.5 Ohm
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Dimension 0.126" L x 0.063" W (3.20mm x 1.59mm)
Thickness (Max) 0.039" (1.00mm)
Approvals CSA, TUV, UL
Win Source Part Number 096174-NANOSMDC012F-2
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Industrial, Computers & Computer Peripherals, Consumer Electronics, Imaging, Video & Vision, Communications & Networking, Automotive
Family Name NANOSMDC
Introduction Date November 09, 2015
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian NANOSMDC012F-2 CAD Model

Description

The Littelfuse Inc. 096174-NANOSMDC012F-2 is a polymeric type electronic component used in various applications.

  • Manufacturer: Littelfuse Inc.
  • Category: circuit protection
  • Supply and Demand Status: sufficient
  • Popularity: high
  • Threat of Fake Products: 48% in the open market
  • Applications: industrial, computers & computer peripherals, consumer electronics, imaging, video & vision, communications & networking, and automotive applications.
