KRD9220B Littelfuse Inc. – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

KRD9220B

Part No KRD9220B
Manufacturer Littelfuse Inc.
Catalog Time Delay Relays
Description RELAY TIME DELAY 10SEC 10A 125V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Mounting Type Chassis Mount
Relay Type Mechanical Relay
Function One Shot
Circuit SPDT (1 Form C)
Delay Time 0.1 Sec ~ 10 Sec
Contact Rating @ Voltage 10A @ 125VAC
Voltage - Supply 24VAC/DC
Termination Style Quick Connect - 0.250" (6.3mm)
Timing Adjustment Method Screwdriver Slot
Timing Initiate Method Input Voltage, Trigger Signal
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1508504-KRD9220B
Ultra Librarian 3D Model Ultra Librarian KRD9220B CAD Model
