0298125.ZXEH Real Image
Same model may have multiple batches, images only for reference.

0298125.ZXEH

Part No 0298125.ZXEH
Manufacturer Littelfuse Inc.
Catalog Fuses
Description FUSE AUTO 125A 32VDC AUTO LINK / 125 A AC 32 V DC Fuse Automotive Bolt Mount Auto Link
Datasheet
0298125.ZXEH Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection>Fuses
Mfr Littelfuse Inc.
Series MEGA®
Package Bulk
Mounting Type Bolt Mount
Fuse Type Automotive
Current Rating (Amps) 125 A
Voltage Rating - DC 32 V
Response Time Slow Blow
Package / Case Auto Link
Breaking Capacity @ Rated Voltage 2kA
Melting I2t 57800
Approval Agency UL
Temperature Range - Operating -40°C ~ 125°C
Color Green
Dimension 1.149" L x 0.750" W x 0.390" H (29.20mm x 19.05mm x 9.90mm)
DC Cold Resistance 0.000423 Ohms
MSL Level Not Applicable
ECCN EAR99
HTSUS 8536.10.0040
Other Names 0298125.ZXEH-ND,0298125ZXEH,F3323,-1024-0298125.ZXEH,298125,298125.
Standard Package 500
Win Source Part Number 1163971-0298125.ZXEH
Ultra Librarian 3D Model Ultra Librarian 0298125.ZXEH CAD Model

Description

The 0298125.ZXEH is a circuit protection fuse in the MEGA® series manufactured by Littelfuse Inc. The product is categorized as a fuse.

  • Category: Fuse
  • Series: MEGA®
  • Win Source Part Number: 1163971-0298125.ZXEH
  • Fuse Type: Board Mount
  • Voltage Rating - DC: 32 V
  • Response Time: Slow Blow
  • Breaking Capacity @ Rated Voltage: 100 A
  • Melting I2t: 2.1
  • Standard Package: 100
  • Mounting Type: SMD (SMT)
  • Package/Case: 2-SMD, J-Lead
  • Temperature Range - Operating: -55°C to 125°C
  • Dimensions: 0.291" L x 0.122" W x 0.102" H (7.40mm x 3.10mm x 2.60mm)
  • Current Rating (Amps): 125 A
