The LTC6900CS5#TRMPBF is a compact, low power, high performance silicon oscillator from Linear Technology that provides a frequency range of 1kHz to 20MHz, which can be set by a single external resistor. This high reliability component is designed to offer a precision frequency solution in a tiny SOT-23 package, making it ideal for space-constrained applications.

Key Features:

• Frequency Range: The device is capable of generating frequencies from 1kHz to 20MHz, which are set by one external resistor. This feature provides flexibility and ease-of-use for a variety of applications.
• Voltage Operation: It operates from a single 2.7V to 5.5V supply, making it suitable for use in both 3V and 5V systems.
• Low Power Consumption: The LTC6900CS5#TRMPBF is optimized for low power consumption, drawing only 1.5mA of supply current at 100kHz, which is ideal for battery-powered devices.
• High Frequency Accuracy: With the ability to set the frequency with one external resistor, the device provides high frequency accuracy and stability.
• Temperature Range: It is designed to operate over the industrial temperature range of -40°C to 85°C, ensuring reliable performance in a wide range of environments.
• Package: The component comes in a compact SOT-23 package, which is highly beneficial for space-constrained applications such as handheld devices.

Applications:

The LTC6900CS5#TRMPBF is versatile and can be used in various applications including but not limited to:

• Portable and battery-powered electronics
• Wireless communications
• Medical devices
• Instrumentation
• Automotive systems

In conclusion, the LTC6900CS5#TRMPBF from Linear Technology is a highly adaptable, low power oscillator that offers precision frequency generation in a small form factor, ideal for modern electronic applications where space and power are at a premium.
