Products specifications Report Issue?

Manufacturer Linear Technology
Packaging Tube/Rail
Status Active
Purpose Temp Monitoring System (Sensor)
Sensor Type Internal and External
Accuracy ±3.5°C Local(Max), ±1.5°C Remote(Max)
Topology ADC, Multiplexer, Voltage Reference
Output Type I2C
Output Alarm Yes
Output Fan Yes
Supply Voltage - Operating 2.9 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 10-MSOP
Win Source Part Number 072551-LTC2990IMS#PBF
Ultra Librarian 3D Model Ultra Librarian LTC2990IMS#PBF CAD Model

Description

LTC2990IMS#PBF - High Performance Quad I²C Voltage, Current, and Temperature Monitor

The LTC2990IMS#PBF is a versatile monitoring system from Linear Technology, designed to track system health and ensure reliability in complex electronics. This integrated circuit provides real-time monitoring of voltage, current, and temperature, making it an essential component for power management and system diagnostic applications.

It features a quad-channel design that can be configured to measure a variety of parameters, including:

  • Four voltages, or
  • Two voltages and two temperatures, or
  • Two voltages, one temperature, and one current

The LTC2990IMS#PBF utilizes an I²C interface for communication, which allows for easy integration into existing systems without the need for extensive rewiring or hardware changes. This interface also enables the device to be part of a daisy-chain configuration, simplifying the connection of multiple devices for monitoring additional points within a system.

The temperature measurements are made possible through the use of internal or external diode sensors, providing flexibility for different application requirements. The voltage measurements range from 0V to 36V, with an accuracy that ensures precise and dependable data. Additionally, the current measurement capability is facilitated through the use of an external sense resistor, giving designers the freedom to set their own measurement range based on specific system needs.

Housed in a compact MSOP-16 package, the LTC2990IMS#PBF is suited for space-constrained applications. It also features a wide operating temperature range, making it reliable in various environmental conditions. Its low supply current makes it an excellent choice for power-sensitive applications.

Overall, the LTC2990IMS#PBF is an invaluable tool for engineers looking to enhance system reliability, perform diagnostics, and improve power management through precise monitoring and control.
