Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Linear Technology
Packaging Tube
Function Temp Monitoring System (Sensor)
Sensor Type Internal and External
Accuracy ±3.5°C Local(Maximum), ±1.5°C Remote(Maximum)
Topology ADC, Multiplexer, Register Bank
Output Type I2C
Output Alarm Yes
Output Fan Yes
Operating Supply Voltage 2.9 V ~ 5.5 V
Operating Temperature Range -40°C ~ 85°C
Mounting SMD
Package 16-TFSOP (0.118", 3.00mm Width)
Manufacturer Package 16-MSOP
Win Source Part Number 783203-LTC2991IMS#PBF
Family Name LTC2991
Introduction Date August 18, 2011
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LTC2991IMS#PBF CAD Model

Description

LTC2991IMS#PBF - High Performance Multi-Channel Voltage, Current, and Temperature Monitor

The LTC2991IMS#PBF is a versatile monitoring system from Linear Technology that provides a comprehensive solution for tracking system health and performance. Designed for precision measurement, it can monitor voltage, current, and temperature across multiple channels, making it an ideal choice for a wide range of applications including system monitoring, power-supply testing, and environmental monitoring.

Key Features:

  • Multi-Channel Monitoring: The LTC2991 can measure voltage, current, and temperature on up to eight channels, providing a detailed overview of system parameters. This allows for simultaneous monitoring of various points in a system, improving diagnostics and system reliability.
  • High Accuracy: With its precision measurement capabilities, the LTC2991 delivers accurate readings, ensuring that the data collected is reliable for making critical decisions.
  • Wide Voltage Range: The device is capable of measuring voltages from -0.5V to +5.5V without external components and can monitor a differential voltage from -0.5V to +80V when using external resistive dividers.
  • Integrated Temperature Sensor: An on-chip temperature sensor provides direct measurement of ambient temperature or the temperature of the device itself, further enhancing the monitoring capabilities.
  • I2C Interface: Communication with the LTC2991 is handled via an I2C interface, allowing for easy integration into existing systems and providing a straightforward method for data retrieval.
  • Configurable Alarms: Programmable thresholds for voltage, current, and temperature allow for the setting of alarms, which can trigger system responses or notifications to prevent damage or system failure.

Applications:

  • Telecommunication Systems
  • Networking Equipment
  • Industrial Systems
  • Computer Servers
  • Power Management

The LTC2991IMS#PBF is packaged in a compact 16-lead MSOP, offering a space-saving solution for systems where board real estate is at a premium. Its robust design ensures reliable operation even in challenging environments, making it a go-to choice for engineers who require comprehensive monitoring with minimal overhead.

Overall, the LTC2991IMS#PBF is a powerful and flexible device that simplifies the task of system monitoring, providing crucial insights into the performance and safety of electrical systems.
