Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Output Type Transistor Driver
Purpose Step-Down
Topology Buck
Number of Outputs 2
Output Phases 2
Supply Voltage - Operating 3.5 V to 30 V
Frequency - Switching 220kHz
Duty Cycle (Max) 99.4%
Synchronous Rectifier Yes
Clock Sync No
Control Features Enable, Frequency Control, Power Good, Soft Start
Temperature Range - Operating 0°C to 85°C (TA)
Case / Package 28-SSOP
Win Source Part Number 303158-LTC1628CG#TRPBF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LTC1628CG#TRPBF CAD Model

Description

Product Overview: LTC1628CG#TRPBF

The LTC1628CG#TRPBF is a high-performance, PolyPhase synchronous step-down switching regulator controller designed by Linear Technology, now part of Analog Devices. This advanced controller is engineered to drive all N-channel power MOSFET stages, which makes it an ideal choice for high-efficiency, high-current voltage regulation in a variety of applications.

Key Features

  • High Efficiency: The LTC1628CG#TRPBF utilizes a constant-frequency, current mode architecture, along with a phase-lockable frequency of up to 550kHz, allowing for smaller inductor sizes and faster transient response.
  • PolyPhase Operation: This controller supports PolyPhase operation, which significantly reduces the required input and output capacitance and the power supply generated heat by distributing the power and load between multiple phases.
  • OPTI-LOOP Compensation: The inclusion of OPTI-LOOP compensation allows the user to optimize the tradeoff between output voltage stability, transient response, and the output capacitor size.
  • Powerful Driver: It comes with powerful onboard 1.5A gate drivers designed to handle large power MOSFETs, ensuring robust and reliable operation even under heavy loads.
  • Voltage Monitoring: The product has precise monitoring and control capabilities, with a RUN pin that allows for easy on/off control, and a power good output indicator for system monitoring.

Applications

The LTC1628CG#TRPBF is versatile and can be used in a wide range of applications, including:

  • Telecommunications infrastructure
  • Industrial systems
  • High-density distributed power systems
  • Computers and servers

Reliability and Packaging

Linear Technology's LTC1628CG#TRPBF is designed for reliability, with built-in overvoltage protection and under-voltage lockout to ensure the safety and longevity of your electronic systems. The device is available in a 36-lead SSOP package, which is RoHS compliant and suitable for high-temperature soldering processes, making it a reliable choice for environmentally conscious and high-reliability designs.

With its advanced features, robust design, and versatile application range, the LTC1628CG#TRPBF is a top-tier solution for those in need of a high-performance power regulation system.
