Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Output Type Transistor Driver
Purpose Step-Down
Topology Buck
Number of Outputs 2
Output Phases 2
Supply Voltage - Operating 3.5 V to 30 V
Frequency - Switching 220kHz
Duty Cycle (Max) 99.4%
Synchronous Rectifier Yes
Clock Sync No
Control Features Enable, Frequency Control, Power Good, Soft Start
Temperature Range - Operating 0°C to 85°C (TA)
Case / Package 28-SSOP
Win Source Part Number 303157-LTC1628CG#TR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LTC1628CG#TR CAD Model

Description

The LTC1628CG#TR is a high-performance, dual step-down switching regulator designed and manufactured by Linear Technology. This advanced power management integrated circuit (IC) is engineered to deliver high efficiency and precise regulation for a variety of applications, including telecommunications, networking equipment, and portable devices.

Key Features:

  • Wide Input Voltage Range: Operates from a 4.5V to 36V input voltage range, making it suitable for a variety of supply sources.
  • Dual Outputs: Features two independent output channels that can provide up to 5A of continuous output current each, ensuring ample power for dual supply applications.
  • Adjustable Switching Frequency: The switching frequency can be programmed between 50kHz to 500kHz or synchronized to an external clock, allowing for flexibility in optimizing efficiency and component size.
  • High Efficiency: Integrated synchronous rectification and a constant frequency current mode architecture contribute to high efficiency levels, reducing heat generation and improving system reliability.
  • Stable Operation: Uses internal or external feedback loop compensation for stable operation with a wide range of output capacitors and inductors.

Protection Features:

  • Overcurrent Protection: Both channels are protected against overcurrent conditions, enhancing the safety and longevity of the device.
  • Soft-Start Capability: Minimizes inrush current during startup, providing a safe and controlled ramp-up of output voltage.
  • Thermal Shutdown: Internal thermal shutdown circuitry prevents the regulator from overheating, ensuring safe operation under all conditions.

Applications:

The LTC1628CG#TR is ideal for a broad range of applications, including:

  • Point-of-Load Regulation
  • Telecommunications Infrastructure
  • Networking Equipment
  • Industrial Systems
  • Portable Electronic Devices

With its robust feature set and high reliability, the LTC1628CG#TR is an excellent choice for designers looking to implement a compact, efficient, and reliable power solution in their next project.
