Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Tube/Rail
Status Active
Output Type Transistor Driver
Purpose Step-Down
Topology Buck
Number of Outputs 2
Output Phases 2
Supply Voltage - Operating 3.5 V to 30 V
Frequency - Switching 220kHz
Duty Cycle (Max) 99.4%
Synchronous Rectifier Yes
Clock Sync No
Control Features Enable, Frequency Control, Power Good, Soft Start
Temperature Range - Operating 0°C to 85°C (TA)
Case / Package 28-SSOP
Win Source Part Number 1060929-LTC1628CG#PBF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LTC1628CG#PBF CAD Model

Description

The LTC1628CG#PBF is a high-performance, PolyPhase synchronous step-down switching regulator controller designed by Linear Technology, now part of Analog Devices. This advanced component is engineered to efficiently manage power supply within a wide range of electronic applications, from computers and telecommunications equipment to industrial systems.

Key Features

  • High Efficiency: The LTC1628CG#PBF employs a synchronous rectification architecture that enhances efficiency, making it suitable for systems where power conservation is critical.
  • PolyPhase Operation: Its PolyPhase operation capability allows multiple LTC1628CG#PBF controllers to be interconnected, spreading the power and thermal load across several phases, which improves performance and reduces system stress.
  • Versatile Voltage Range: This controller operates with an input voltage range from 4.5V to 36V, accommodating a variety of power sources and ensuring flexibility in system design.
  • Adjustable Switching Frequency: Users can set the switching frequency anywhere from 50kHz to 550kHz or synchronize it to an external clock, providing design customization to meet specific application requirements.
  • OPTI-LOOP Compensation: The LTC1628CG#PBF features OPTI-LOOP compensation, which allows the optimization of transient response, output voltage stability, and loop bandwidth.

Protection Features

  • Overcurrent Protection: The product includes foldback current limiting for system protection, ensuring safe operation under abnormal conditions.
  • Overvoltage Protection: It is equipped with overvoltage protection that guards the system against voltage spikes and surges.
  • Soft-Start Capability: The soft-start feature reduces inrush current during startup, contributing to the longevity of the system.

Applications

The LTC1628CG#PBF is ideal for a wide range of applications, including:

  • High-density power distribution systems
  • Telecommunications infrastructure
  • Networking equipment
  • Industrial systems
  • Servers and computer systems

With its robust design and comprehensive feature set, the LTC1628CG#PBF from Linear Technology is a versatile and reliable choice for managing power in complex electronic systems.
