LT4363IMS-2#TRPBF

Part No LT4363IMS-2#TRPBF
Manufacturer Linear Technology
Catalog Surge Suppression ICs
Description IC SURGE STOPPER HV 12-MSOP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Linear Technology/Analog Devices
Packaging Reel
Voltage - Clamping 27V Adj
Technology External Switch
Applications Automotive
Mounting Style SMD
Manufacturer Package 12-TSSOP
Supplier Device Package 12-MSOP
Voltage - Working 4 ~ 80V
Family Part Number LT4363
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 714992-LT4363IMS-2#TRPBF
Popularity Low
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LT4363IMS-2#TRPBF CAD Model

Description

Product Overview: LT4363IMS-2#TRPBF

The LT4363IMS-2#TRPBF is a high-performance surge stopper device designed by Linear Technology to provide robust protection against high voltage transients and surges. This component is essential for safeguarding sensitive electronic circuits from voltage spikes that can occur due to lightning strikes, load dump in vehicles, or power supply overvoltage. It is a versatile solution that can be used across a wide range of applications including automotive, industrial, avionics, and power management systems.

Key Features

  • Wide Operating Voltage Range: The LT4363IMS-2#TRPBF operates effectively across a voltage range of 4V to 80V, making it suitable for a variety of power systems.
  • Adjustable Overvoltage Control: Users can set the overvoltage shutdown threshold to meet the specific requirements of their application, ensuring precise control over the protection parameters.
  • Overcurrent Protection: The device includes a feature to limit the output current during overvoltage events, preventing damage to downstream components.
  • Low Quiescent Current: It has a low current draw in shutdown mode, which helps to minimize power consumption when the device is not actively protecting the circuit.
  • Robust Thermal Performance: The LT4363IMS-2#TRPBF is housed in an MSOP-16 package, which offers excellent thermal performance and is suitable for high-temperature environments.
  • Reverse Input Protection: The device is capable of withstanding negative input voltages without damage, further enhancing its protective capabilities.

Applications

  • Automotive Electronics
  • Industrial Control Systems
  • Avionics and Aerospace Systems
  • Power Supply Protection
  • Telecommunication Infrastructure

The LT4363IMS-2#TRPBF is available in a surface-mount package, which is ideal for compact designs where space is at a premium. Its robust design ensures that it can handle the rigors of tough electrical environments, making it a reliable choice for critical applications where circuit protection is paramount. With its combination of features, the LT4363IMS-2#TRPBF from Linear Technology stands out as a comprehensive solution for safeguarding electronic systems against voltage-related damages.
