ISP814A Isocom Components 2004 LTD
Same model may have multiple batches, images only for reference.

ISP814A

Part No ISP814A
Manufacturer Isocom Components 2004 LTD
Catalog Misc Products
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Uncategorized
Manufacturer Isocom Components 2004 LTD
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 826291-ISP814A
Package Tube
Product Status Active
Number of Channels 1
Voltage - Isolation 5300Vrms
Current Transfer Ratio (Min) 50% @ 1mA
Current Transfer Ratio (Max) 150% @ 1mA
Rise / Fall Time (Typ) 4µs, 3µs
Input Type AC, DC
Output Type Transistor
Voltage - Output (Max) 35V
Current - Output / Channel 50mA
Voltage - Forward (Vf) (Typ) 1.2V
Current - DC Forward (If) (Max) 50mA
Vce Saturation (Max) 200mV
Grade -
Operating Temperature -30°C ~ 100°C
Mounting Type Through Hole
Package / Case 4-DIP (0.300", 7.62mm)
Supplier Device Package 4-DIP
Ultra Librarian 3D Model Ultra Librarian ISP814A CAD Model

Description

The ISP814A is an electronic component manufactured by Isocom Components 2004 LTD.

  • It is a part of the uncategorized category and has a medium popularity in the market.
  • The component is designed to be used in various electronic devices, and it has a unique set of specifications that make it suitable for specific applications.
  • The ISP814A is a reliable and efficient component that can help improve the performance of electronic devices.
