The IRF7309TR is a dual P-Channel MOSFET from International Rectifier, designed for space-constrained power switching applications. The 'TR' suffix indicates that the component is provided on tape and reel for automated assembly.

Applications

• Load switching in portable devices
• Power management in battery-powered systems
• DC-DC converters
• High-side switching
• Solid state relays

Features

• Dual P-Channel MOSFETs
• Low on-resistance (RDS(on))
• Fast switching speed
• Surface mount package (typically SO-8)
• Logic-level gate drive
• RoHS compliant

Benefits

• Reduces board space requirements
• Minimizes power losses in switching circuits
• Enables efficient power conversion
• Simplifies interfacing with logic-level circuits
• Suitable for automated assembly

Additional Details

The IRF7309TR integrates two P-Channel MOSFETs in a single SO-8 package, reducing board space compared to using two discrete MOSFETs. It typically has a drain-source voltage (Vds) rating of -30V and a gate-source voltage (Vgs) rating of ±20V. The low on-resistance minimizes conduction losses, leading to improved energy efficiency. The fast switching speed minimizes switching losses, enabling high-frequency operation. The logic-level gate drive allows direct interfacing with microcontrollers and other logic circuits, simplifying the design. The SO-8 package allows for efficient heat dissipation. This dual MOSFET is ideal for applications where board space is limited and efficient power switching is required. International Rectifier is now part of Infineon Technologies; datasheets and supporting documentation can be found on the Infineon website.
