IRFP3206PBF

Name: IRFP3206PBF
Brand: Infineon Technologies
SKU: 160558
Availability: InStock
Rating: 4.84 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRFP3206PBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	Trans MOSFET N-CH Si 60V 200A 3-Pin(3+Tab) TO-247AC Tube / MOSFET N-CH 60V 120A TO-247AC
Datasheet	IRFP3206PBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Bulk
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	60V
Continuous Drain Current at 25°C	120A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Gate-Source Threshold Voltage	4V @ 150μA
Max Gate Charge	170nC @ 10V
Max Input Capacitance	6540pF @ 50V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	280W (Tc)
Maximum Rds On at Id,Vgs	3 mOhm @ 75A, 10V
Temperature Range - Operating	-55°C to 175°C (TJ)
Mounting	Through Hole
Case / Package	TO-247AC
Dimension	TO-247-3
Win Source Part Number	083590-IRFP3206PBF
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	IRFP3206
Introduction Date	March 03, 2008
ECCN	EAR99
Country of Origin	Mexico
Halogen Free	Compliant
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian IRFP3206PBF CAD Model

Description

The Infineon Technologies IRFP3206PBF is an N-Channel MOSFET transistor with a drain-source breakdown voltage of 60V and a continuous drain current of 120A at 25°C.

Drain-Source Breakdown Voltage: 60V
Continuous Drain Current: 120A at 25°C
Power Dissipation: 280W (Tc)
Package: TO-247AC
Maximum Gate-Source Voltage: ±20V
Maximum Rds On at Id,Vgs: 3 mOhm @ 75A, 10V
Drive Voltage: 10V (Max)
Production Status: Active
