Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Not For New Designs
Motor Type - AC, DC Brushed DC
Purpose Driver - Fully Integrated, Control and Power Stage
Technology Power MOSFET
Applications General Purpose
Output Current 70A
Supply Voltage - Operating 8 V to 18 V
Voltage - Load 8 V to 18 V
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package PG-TO263-7
Win Source Part Number 84079-BTN7970B
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BTN7970B CAD Model

Description

BTN7970B Description

The BTN7970B is a robust and versatile Smart Power Drive, ideal for high-current applications. It features an integrated driver IC with high-side and low-side switches, ensuring reliable performance in harsh conditions.

  • Applications:
    • DC motor control in electric vehicles
    • PWM applications in industrial automation
    • Powered systems in agricultural equipment
  • Features and Benefits:
    • Enhanced thermal performance with built-in thermal protection
    • Flexible operation with integrated logic functions
    • Low electromagnetic emission due to optimized switching

    This power device is perfect for applications where efficient and safe power supply is critical.
