The BUS22 is an NPN transistor manufactured by Inchange Semiconductor Company Limited. It is designed for high-voltage, high-current switching and amplification applications. This transistor is commonly used in power supplies, motor control circuits, and other industrial applications where reliable switching performance is critical.

Applications

• Power Supplies (Switching Regulators)
• Motor Control Circuits
• Inverters
• Lighting Ballasts
• High-Voltage Amplifiers

Features

• High Voltage: Collector-Emitter Voltage (VCEO) of up to 700V, suitable for high-voltage applications.
• High Current: Continuous Collector Current (IC) of up to 8A.
• Fast Switching Speed: Allows for efficient switching operations.
• Low Saturation Voltage: Reduces power dissipation and improves efficiency.
• High Reliability: Robust design ensures stable operation in demanding conditions.

Benefits

• Versatile Applications: Suitable for a wide range of high-voltage and high-current switching applications.
• Efficient Performance: Low saturation voltage and fast switching speed minimize power losses.
• Reliable Operation: Designed for stable performance in industrial environments.

Technical Specifications:

• Transistor Type: NPN
• Collector-Emitter Voltage (VCEO): 700V
• Collector-Base Voltage (VCBO): 700V
• Emitter-Base Voltage (VEBO): 9V
• Collector Current (IC): 8A
• Base Current (IB): 2A
• Power Dissipation (PC): 80W
• Operating Temperature: -65°C to +150°C
• Package: TO-220
