Manufacturer HY ELECTRONIC CORP.
Win Source Part Number 1135058-ABS18
Manufacturer Homepage www.hygroup.com.tw
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ABS18 CAD Model

Description

The ABS18 is a bridge rectifier manufactured by HY Electronic Corp. Bridge rectifiers are commonly used in power supplies to convert AC voltage to DC voltage. The ABS18 is designed for through-hole mounting and offers a compact solution for rectification needs.

Applications:

  • Power supplies for consumer electronics
  • Adapters for charging devices
  • LED lighting systems
  • Industrial control equipment
  • Battery chargers

Features:

  • High Surge Current Capability: Designed to withstand high surge currents.
  • Low Forward Voltage Drop: Minimizes power loss during rectification.
  • High Reliability: Ensures stable performance in various applications.
  • Through-Hole Mounting: Easy to install on PCBs.
  • Compact Size: Saves space on circuit boards.

Benefits:

  • Efficient AC to DC Conversion: Provides a stable DC output.
  • Enhanced System Reliability: Robust design ensures long-term performance.
  • Easy Integration: Simple through-hole mounting.
  • Cost-Effective Solution: Offers excellent performance at a competitive price.
  • Wide Range of Applications: Suitable for various electronic devices.

Technical Specifications (Typical):

  • Repetitive Peak Reverse Voltage (Vrrm): 1000V
  • RMS Reverse Voltage (Vrrms): 700V
  • DC Blocking Voltage (Vdc): 1000V
  • Maximum Average Forward Rectified Current (If(AV)): 1.5A
  • Peak Forward Surge Current (Ifsm): 50A
  • Forward Voltage (Vf): 1.0V
  • Operating Temperature Range: -55°C to +150°C
  • Package: ABS

The ABS18 bridge rectifier from HY Electronic Corp. provides reliable and efficient AC to DC conversion for a wide range of applications. Its compact size, high surge current capability, and low forward voltage drop make it an excellent choice for modern electronic designs. It is commonly used in power supplies, adapters, and various industrial applications where AC voltage needs to be converted to DC voltage.
