The UFF160-02CT is a high-efficiency ultrafast rectifier manufactured by Frontier Electronics. It's designed for use in high-frequency switching power supplies, inverters, and other applications where fast recovery and low forward voltage drop are crucial.

Applications:

• Switching Mode Power Supplies (SMPS).
• Power Factor Correction (PFC).
• Inverters.
• Freewheeling diodes in motor control circuits.
• High-frequency rectification.

Features:

• Ultrafast recovery time.
• Low forward voltage drop.
• High surge current capability.
• High reliability.
• Low reverse leakage current.
• Isolation voltage 2500V

Benefits:

• Improved efficiency in switching power supplies.
• Reduced power dissipation.
• Enhanced system reliability due to robust design.
• Minimized switching losses.
• Lower operating temperature.

Technical Specifications:

• Repetitive Peak Reverse Voltage (VRRM): 200V
• Average Forward Current (IF(AV)): 16A
• Peak Forward Surge Current (IFSM): 150A
• Forward Voltage (VF): 0.95V at 8A
• Reverse Recovery Time (trr): 35ns
• Operating Junction Temperature (Tj): -55°C to +150°C
• Package: TO-220

The UFF160-02CT ultrafast rectifier provides an excellent solution for improving efficiency and reliability in high-frequency power conversion applications. Its fast recovery time minimizes switching losses, while its low forward voltage drop reduces power dissipation. The robust design ensures high surge current capability and reliable operation in demanding environments. It's packaged in a TO-220 configuration for ease of mounting and thermal management.
