Same model may have multiple batches, images only for reference.
HCPL2630SDV Real Image
Same model may have multiple batches, images only for reference.

HCPL2630SDV

Part No HCPL2630SDV
Manufacturer Fairchild/ON Semiconductor
Catalog Optoisolators - Logic Output
Description High Speed 10MBit/s Logic Gate Optocouplers
Datasheet
HCPL2630SDV Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Number of Channels 2
Inputs - Side 1/Side 2 2/0
Voltage - Isolation 2500Vrms
Common Mode Transient Immunity (Minimum) 10kV/μs (Typ)
Input Type DC
Output Type Open Collector
Output Current per Channel 50mA
Data Rate 10Mbps
Propagation Delay tpLH / tpHL (Maximum) 75ns, 75ns
Rise / Fall Time (Typ) 50ns, 12ns
Voltage - Forward (Vf) (Typ) 1.4V
Current - DC Forward (If) (Maximum) 30mA
Operating Supply Voltage 4.5 V ~ 5.5 V
Operating Temperature Range -40°C ~ 85°C
Mounting SMD
Package 8-SMD, Gull Wing
Manufacturer Package 8-SMD
Win Source Part Number 1179087-HCPL2630SDV
Manufacturer Homepage www.fairchildsemi.com
Popularity Medium
Supply and Demand Status Limited
Family Name HCPL2630
Introduction Date January 26, 2000
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2024
Quantity per package 1k pcs
Ultra Librarian 3D Model Ultra Librarian HCPL2630SDV CAD Model

Description

The HCPL2630SDV is a 2-channel isolator manufactured by Fairchild/ON Semiconductor. Fairchild/ON Semiconductor manufactures it.

  • Output Type: Open Collector
  • Input Type: DC
  • Voltage Isolation: 2500Vrms
  • Data Rate: 10Mbps
  • Operating Temperature: -40°C to 85°C
  • Package: 8-SMD, Gull Wing
  • Compliance: Halogen-Free
  • Estimated EOL Date: 2024
