HCPL0600R2

Name: HCPL0600R2
Brand: Fairchild/ON Semiconductor
SKU: 141808
Availability: InStock
Rating: 4.85 (49 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	HCPL0600R2
Manufacturer	Fairchild/ON Semiconductor
Catalog	Optoisolators - Logic Output
Description	OPTOISO 3.75KV OPN COLLECTOR 8SO
Datasheet	HCPL0600R2 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Isolators
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Active
Number of Channels	1
Inputs - Side 1/Side 2	1/0
Isolation Voltage	3750Vrms
Common Mode Transient Immunity (Min)	5kV/μs
Input Type	DC
Output Type	Open Collector
Channel Output Current	50mA
Data Rate	10Mbps
Propagation Delay tpLH / tpHL (Max)	75ns, 75ns
Rise and Fall Time	50ns, 12ns
Forward Voltage	1.75V (Max)
Continuous forward current- Max	50mA
Supply Voltage - Operating	4.5 V to 5.5 V
Temperature Range - Operating	-40°C to 85°C
Mounting	SMD (SMT)
Case / Package	8-SO Tall
Win Source Part Number	016833-HCPL0600R2
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Family Name	HCPL0600
Introduction Date	July 01, 2005
ECCN	EAR99
Country of Origin	Japan, Thailand
Halogen Free	Compliant
Estimated EOL Date	2024
Quantity per package	2,500
Ultra Librarian 3D Model	Ultra Librarian HCPL0600R2 CAD Model

Description

The HCPL0600R2 is an isolator component manufactured by Fairchild/ON Semiconductor. It is a single-channel device.

Output Type: Open Collector
Data Rate: 10Mbps
Common Mode Transient Immunity: ≥ 5kV/μs
Propagation Delay (tpLH/tpHL): 75ns / 75ns
Isolation Voltage: 3750Vrms
Package: 8-SO Tall
Operating Temperature: -40°C to 85°C
Supply Voltage: 4.5V to 5.5V
Channel Output Current: 50mA
Continuous Forward Current: 50mA
Quantity per Package: 2,500
