ESP32-D0WDQ6 Real Image ESP32-D0WDQ6 real image22970
Same model may have multiple batches, images only for reference.
ESP32-D0WDQ6 Real Image ESP32-D0WDQ6 real image22970
ESP32-D0WDQ6 Real Image ESP32-D0WDQ6 real image22970
Same model may have multiple batches, images only for reference.

ESP32-D0WDQ6

Part No ESP32-D0WDQ6
Manufacturer Espressif
Catalog RF Transceiver ICs
Description IC RF TXRX+MCU BLUETOOTH 48VFQFN / 32-bit MCU & 2.4 GHz Wi-Fi & BT/BLE SoCs
Datasheet
ESP32-D0WDQ6 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Espressif Systems
Packaging Reel
Type TxRx + MCU
RF Family/Standard Bluetooth, WiFi
Protocol 802.11b/g/n, Bluetooth 4.2
Frequency 2.4GHz
Data Rate (Maximum) 150Mbps
Power - Output 20dBm
Sensitivity -98dBm
Memory Size 448kB ROM, 520kB SRAM
Serial Interfaces I2C, I2S, SPI, UART
GPIO 34
Supply Voltage (V) 2.3V ~ 3.6V
Current - Receiving 100mA
Current - Transmitting 240mA
Temperature Range - Operating -40°C ~ 125°C
Manufacturer Package 48-VFQFN Exposed Pad
Manufacturer Pack Quantity 1,000
MSL Level 3 (168 Hours)
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 810951-ESP32-D0WDQ6
Ultra Librarian 3D Model Ultra Librarian ESP32-D0WDQ6 CAD Model

Description

The Espressif ESP32-D0WDQ6 is a high-performance RF transceiver module that operates at a frequency of 2.4GHz. With a package of 48-VFQFN Exposed Pad, this module is ideal for surface mount applications.

  • Protocols: 802.11b/g/n, Bluetooth 4.2
  • Data Rate: 150Mbps
  • ROM Memory Size: 448kB
  • SRAM Memory Size: 520kB
  • Sensitivity: -98dBm
