The M13S2561616AS-5TG2S is a 256Mb SDRAM (Synchronous Dynamic Random-Access Memory) chip manufactured by ESMT. This memory chip is designed for applications that require high-speed data access and substantial memory capacity. It is commonly found in embedded systems, networking devices, and various consumer electronics.

Applications:

• Embedded Systems
• Networking Devices (Routers, Switches)
• Consumer Electronics (Set-Top Boxes, Digital TVs)
• Industrial Control Systems
• Gaming Consoles

Features:

• Capacity: 256Mb (16Mb x 16)
• Organization: Configured as 16 Meg x 16 bits
• Interface: Standard SDRAM interface
• Clock Rate: Supports clock rates up to 133MHz (based on -5 speed grade)
• Power Supply: Operates at standard SDRAM voltage (e.g., 3.3V)
• Refresh: Auto and Self Refresh modes available
• Package: Available in various package options, including TSOP and BGA
• Temperature Range: Supports commercial and industrial temperature ranges

Benefits:

• High Performance: Enables fast data access, enhancing system responsiveness and overall performance.
• Low Power Consumption: Designed to minimize power consumption, which is crucial for battery-powered and energy-efficient applications.
• Reliability: Ensures stable and reliable operation in various operating conditions.
• Compact Size: Available in compact packages for space-constrained designs.
• Cost-Effective: Provides a balance of high performance and reasonable cost.

Additional Details:

The M13S2561616AS-5TG2S utilizes a synchronous interface for high-speed data transfers. It supports burst read and write operations, improving data throughput. Auto-refresh and self-refresh modes are included for efficient power management and data retention. The datasheet provided by ESMT contains precise timings and electrical characteristics for this device. The '-5TG2S' designation refers to specific attributes of the speed grade and packaging.
