Same model may have multiple batches, images only for reference.
DRAQ127-220-R Eaton Bussmann – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

DRAQ127-220-R

Part No DRAQ127-220-R
Manufacturer Eaton Bussmann
Catalog Arrays, Signal Transformers
Description INDUCT ARRAY 2 COIL 22UH SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Number of Coils 2
Inductance - Connected In Parallel 22 µH
Inductance - Connected In Series 88 µH
Tolerance ±25%
Current Rating - Parallel 3.98 A
Current Rating - Series 1.99 A
Current Saturation - Parallel 6.05 A
Current Saturation - Series 3.03 A
DC Resistance (DCR) - Parallel 47mOhm Max
DC Resistance (DCR) - Series 192mOhm Max
Shielding Shielded
Ratings AEC-Q200
Temperature Range - Operating -40°C ~ 165°C
Mounting Type Surface Mount
Case / Package Nonstandard
Size / Dimension 0.480" L x 0.480" W (12.20mm x 12.20mm)
Height 0.315\
Package Tape & Reel
Supply and Demand Status Shortage
Win Source Part Number 1530695-DRAQ127-220-R
Ultra Librarian 3D Model Ultra Librarian DRAQ127-220-R CAD Model
