PF0553.683NLT Real Image
Same model may have multiple batches, images only for reference.

PF0553.683NLT

Part No PF0553.683NLT
Manufacturer Pulse
Catalog Arrays, Signal Transformers
Description INDUCT ARRAY 2 COIL 66UH SMD / Inductor Power Shielded Wirewound 66uH/270uH 20% 100KHz 2.4A/1.2A 0.11Ohm/0.42Ohm DCR Automotive T/R
Datasheet
PF0553.683NLT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Inductors, Coils, Chokes
Manufacturer Pulse Electronics Corporation
Series PF0553NL
Packaging Reel package
Number of Coils 2
Test Inductance - Connected In Series 270μH
Inductance - Connected In Parallel 66μH
Tolerance ±20%
Current Rating - Parallel 2.4A
Current Rating - Series 1.2A
Current Saturation - Parallel 4.4A
Current Saturation - Series 2.2A
DC Resistance (DCR) - Parallel 110 mOhm Max
DC Resistance (DCR) - Series 420 mOhm Max
Shielding Shielded
Operating Temperature Range -40°C ~ 125°C
Mounting SMD
Package Nonstandard
Dimension 0.492" L x 0.492" W (12.50mm x 12.50mm)
Height 0.315" (8.00mm)
Win Source Part Number 791722-PF0553.683NLT
Popularity Medium
Supply and Demand Status Limited
Family Name PF0553NL
Introduction Date August 11, 2005
ECCN EAR99
Country of Origin China
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian PF0553.683NLT CAD Model

Description

The Pulse Electronics Corporation PF0553.683NLT is an inductor that is used in electronic devices from Pulse Electronics Corporation.

  • Win Source Part Number: 791722-PF0553.683NLT
  • Parallel Inductance: 66μH
  • Series Test Inductance: 270μH
  • Parallel Current: 2.4A
  • Series Current: 1.2A
  • Parallel DC Resistance (Max): 110 mOhm
  • Series DC Resistance (Max): 420 mOhm
  • Supply and Demand: Limited
