The PI5A3158BZAEX is a high-performance, single-pole double-throw (SPDT) analog switch from Diodes Incorporated, designed to deliver a combination of high-speed operation, low power consumption, and compact packaging. This switch is an ideal choice for a wide range of applications, including signal routing, data acquisition systems, and communications equipment.

Key Features

• Low On-Resistance: The PI5A3158BZAEX boasts a low on-resistance (typically 0.5Ω), which ensures minimal signal distortion and power loss when the switch is in the ON state.
• Wide Operating Voltage Range: This device operates over a wide voltage range of 2.3V to 5.5V, making it versatile for both 3.3V and 5V systems.
• High-Speed Switching: Fast switch times (tON and tOFF) of approximately 0.1µs make the PI5A3158BZAEX suitable for high-speed applications.
• Low Power Consumption: With a quiescent current of less than 1µA, the switch minimizes power consumption in battery-powered portable devices.
• Break-Before-Make Switching: The PI5A3158BZAEX features break-before-make switching, which prevents momentary shorting when switching between signals.
• ESD Protection: Enhanced electrostatic discharge (ESD) protection is built-in, withstanding up to 2kV Human Body Model.

Applications

The versatile nature of the PI5A3158BZAEX allows its use in a variety of applications, including but not limited to:

• Audio and video signal routing
• Cellular phones and PDAs
• Portable instrumentation
• Data acquisition systems
• Communication systems

Package and Quality

The PI5A3158BZAEX is available in an ultra-small X2-DFN1410-6 package, which is ideal for space-constrained applications. The product adheres to Diodes Incorporated's commitment to quality and reliability, ensuring performance and longevity in the field.

Ordering Information

To order or request samples of the PI5A3158BZAEX, or to view detailed technical specifications, visit the Diodes Incorporated website or contact your local Diodes Incorporated sales representative.
