DMMT5551S-7-F

Part No DMMT5551S-7-F
Manufacturer Diodes Incorporated
Catalog Transistors (BJT) - Arrays
Description TRANS 2NPN 160V 0.2A SOT26
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Diodes Incorporated
Packaging Reel - TR
Status Active
Transistor Polarity 2 NPN (Dual) Matched Pair
Maximum Current Collector 200mA
VCEO Maximum Collector-Emitter Breakdown Voltage 160V
Max Vce (sat) 200mV @ 5mA, 50mA
Collector Cut-off Current(Max) 50nA (ICBO)
Typical Gain (hFE) (Min) 80 @ 10mA, 5V
Maximum Power Dissipation 300mW
Frequency - Transition 300MHz
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-26
Win Source Part Number 014402-DMMT5551S-7-F
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian DMMT5551S-7-F CAD Model

Description

The DMMT5551S-7-F is a high-performance, dual NPN transistor from Diodes Incorporated, designed to deliver a combination of low voltage operation and high efficiency, making it suitable for a wide range of applications. This transistor is housed in a compact SOT-363 package, which is known for its small footprint and excellent power handling capabilities.

Key Features

  • Transistor Type: Dual NPN
  • Package: SOT-363
  • Configuration: Single
  • Collector-Emitter Voltage (VCEO): 40V
  • Collector-Base Voltage (VCBO): 80V
  • Emitter-Base Voltage (VEBO): 6V
  • Continuous Collector Current (IC): 600mA
  • Power Dissipation (Pd): 300mW
  • DC Current Gain (hFE): 100 to 600
  • Operating Temperature Range: -55°C to +150°C

Applications

The DMMT5551S-7-F is ideal for a variety of applications, including but not limited to:

  • Power management circuits
  • Switching regulators
  • Signal amplification
  • Driver stages in audio amplifiers
  • Multiple configuration logic-level conversion

Quality and Reliability

Diodes Incorporated is committed to providing high-quality products. The DMMT5551S-7-F is manufactured with the highest standards ensuring reliable performance and longevity. This product is lead-free, halogen-free, and RoHS compliant, reflecting Diodes Incorporated's dedication to environmental responsibility.

Support and Resources

Customers can access comprehensive technical support and resources for the DMMT5551S-7-F, including datasheets, application notes, and design tools, directly through the Diodes Incorporated website or through authorized distributors. This ensures that designers can efficiently integrate this component into their projects with confidence and ease.
