C4D10120E Cree Inc.
Same model may have multiple batches, images only for reference.

C4D10120E

Part No C4D10120E
Manufacturer Cree/Wolfspeed
Catalog Diodes, Rectifiers - Single
Description DIODE SIL CARB 1.2KV 33A TO252-2
Datasheet
C4D10120E Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr Cree/Wolfspeed
Series Z-Rec®
Package Tube
Product Status Active
Technology SiC (Silicon Carbide) Schottky
Voltage - DC Reverse (Vr) (Max) 1200 V
Current - Average Rectified (Io) 33A
Voltage - Forward (Vf) (Max) @ If 1.8 V @ 10 A
Speed No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr) 0 ns
Current - Reverse Leakage @ Vr 250 µA @ 1200 V
Capacitance @ Vr, F 754pF @ 0V, 1MHz
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Supplier Device Package TO-252-2
Operating Temperature - Junction -55°C ~ 175°C
Base Product Number C4D10120
Standard Package 75 pcs
ECCN EAR99
HTSUS 8541.10.0080
California Prop 65 Warning Information
Win Source Part Number 575824-C4D10120E
Ultra Librarian 3D Model Ultra Librarian C4D10120E CAD Model

Description

The 575824-C4D10120E is a rectifier diode from the Z-Rec™ series by Cree/Wolfspeed.

  • Series: Z-Rec™
  • Type: SiC (Silicon Carbide) Schottky Diode
  • Maximum DC Reverse Voltage: 1200V
  • Average Rectified Current: 33A
  • Forward Voltage: 1.8V @ 10A
  • Reverse Recovery Time: 0ns
  • Current Leakage: 250µA @ 1200V
  • Capacitance: 754pF @ 0V and 1MHz
  • Operating Temperature Range: -55°C to 175°C
  • Mounting Type: Surface Mountable
  • Package: TO-252-3
  • Package Quantity: 75 pieces
  • Product Status: Active
  • Category: Discrete Semiconductor Products
