Same model may have multiple batches, images only for reference.

SLP103M035C4P3

Name: SLP103M035C4P3
Brand: Cornell Dubilier Electronics (CDE)
SKU: 1308100
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	SLP103M035C4P3
Manufacturer	Cornell Dubilier Electronics (CDE)
Catalog	Aluminum Capacitors
Datasheet	SLP103M035C4P3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Capacitors>Aluminum Electrolytic Capacitors
Mfr	Cornell Dubilier Electronics (CDE)
Series	SLP0712TE (750W)
Package	Bulk
Capacitance	10000 µF
Tolerance	±20%
Voltage - Rated	35 V
ESR (Equivalent Series Resistance)	53mOhm @ 120Hz
Lifetime @ Temp.	3000 Hrs @ 105°C
Temperature Range - Operating	-40°C ~ 105°C
Polarization	Polar
Applications	General Purpose
Ripple Current @ Low Frequency	3.2 A @ 120 Hz
Ripple Current @ High Frequency	4 A @ 20 kHz
Lead Spacing	0.394" (10.00mm)
Dimension	0.984" Dia (25.00mm)
Height - Seated (Max)	1.772" (45.00mm)
Mounting Type	Through Hole
Package / Case	Radial, Can - Snap-In
Standard Package	100
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8532.22.0040
Win Source Part Number	1308100-SLP103M035C4P3
Ultra Librarian 3D Model	Ultra Librarian SLP103M035C4P3 CAD Model

Description

The Cornell Dubilier Electronics (CDE) SLP0712TE (750W) series capacitor is an aluminum electrolytic capacitor with a capacitance of 10000 µF and a voltage rating of 35 V.

Mounting Type: Through-hole
Lead Spacing: 0.394" (10.00mm)
Package/Case: Radial, can - snap-in
Height: 1.772" (45.00mm) when seated
Diameter: 0.984" (25.00mm)
ESR (Equivalent Series Resistance): 53mOhm @ 120Hz
Lifetime: 3000 Hrs @ 105°C
Win Source Part Number: 1308100
