The XAL6030-222MEC is a high-current, shielded power inductor manufactured by Coilcraft. It is designed for use in power supplies, DC-DC converters, and other power applications where high efficiency and low EMI are required. This inductor is characterized by its low DCR (DC resistance) and high saturation current, making it suitable for demanding power applications.

Applications

• DC-DC Converters: Used in DC-DC converters for energy storage and filtering.
• Power Supplies: Employed in power supplies to reduce ripple and improve efficiency.
• Filtering: Incorporated in filtering circuits to reduce noise and interference.
• Voltage Regulators: Used in voltage regulators for stable and efficient voltage regulation.
• LED Lighting: Employed in LED lighting systems for power management and filtering.

Features

• Shielded Construction: Features a shielded construction to minimize EMI (electromagnetic interference).
• High Current Handling: Designed for high current handling capabilities.
• Low DCR (DC Resistance): Offers low DCR to minimize power loss and improve efficiency.
• High Saturation Current: Provides a high saturation current to prevent inductance drop under high current conditions.
• Surface Mount: Available in a surface-mount package for easy PCB assembly.
• RoHS Compliant: Compliant with RoHS standards for environmental protection.

Benefits

• Reduced EMI: Shielded construction minimizes electromagnetic interference.
• High Efficiency: Low DCR minimizes power loss and improves overall efficiency.
• Compact Solution: Surface-mount package allows for high-density PCB layouts.
• Reliable Performance: Designed for stable and reliable operation in various environments.
• Stable Inductance: High saturation current ensures stable inductance under high current conditions.

Additional Details

The XAL6030-222MEC has an inductance value of 2.2 μH (microhenries). It is available in a surface-mount package. The shielded construction helps to contain the magnetic field, reducing interference with other components on the PCB. The low DCR minimizes power loss due to resistive heating, improving the efficiency of the power circuit. For optimal performance, it is essential to consult the manufacturer's datasheet for detailed electrical characteristics, mechanical dimensions, and recommended soldering guidelines.

This power inductor stores energy in the form of a magnetic field when current flows through it. It opposes changes in current flow, which helps to smooth out the current and voltage in power circuits. The high saturation current rating ensures that the inductor can handle high current levels without experiencing a significant drop in inductance.
