Part No BJ77TL
Manufacturer Cinch Connectivity Solutions
Catalog Coaxial Connectors (RF)
Description CONN TRB JACK STR SOLDER
Datasheet
BJ77TL Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Connectors, Interconnects
Manufacturer Cinch Connectivity Solutions Trompeter
Packaging Bulk
Status Active
Connector Style TRB, Twinaxial/Triaxial
Connector Type Jack, Female Socket (Concentric)
Contact Termination Solder Cup
Shield Termination Solder Tag
Impedance Non-Constant
Mounting Panel Mount
Mounting Feature Bulkhead - Rear Side Nut
Fastening Type Bayonet Lock
Maximum Input Frequency 500MHz
Features Extended Insulation
Housing Color Silver
Includes 3 pcs - 1 Connector, 1 Nut, 1 Washer
Body Material Brass
Body Finish Nickel
Center Contact Plating Gold
Temperature Range - Operating -65°C to 165°C
Center Contact Material Beryllium Copper
Voltage Rating 400V
Mating Cycles 500
Win Source Part Number 1021709-BJ77TL
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BJ77TL CAD Model

Description

The TRB series from Cinch Connectivity Solutions Trompeter is a high-quality range of Twinaxial/Triaxial D-Sub Connectors.

  • Connector Type: jack female socket (concentric)
  • Fastening Type: bayonet lock
  • Termination: solder cup
  • Voltage Rating: 400V
  • Housing Color: silver
  • Impedance: non-constant
  • Mounting Feature: bulkhead-rear side nut
  • Body Material: brass
  • Body Finish: nickel
  • Center Contact Material: beryllium copper with gold plating
  • Dielectric Material: Polytetrafluoroethylene (PTFE)
  • Temperature Range: -65°C to 165°C
  • Maximum Input Frequency: 500MHz
  • Mounting: panel mountable
