BJ77HS

Part No BJ77HS
Manufacturer Cinch Connectivity Solutions
Catalog Coaxial Connectors (RF)
Description CONN TRB JACK STR SOLDER / TRB, Twinaxial/Triaxial Connector Jack, Female Socket (Concentric) Non-Constant Panel Mount Solder
Datasheet
BJ77HS Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Coaxial Connectors (RF)
Mfr Cinch Connectivity Solutions Trompeter
Series 70
Package Bulk
Connector Style TRB, Twinaxial/Triaxial
Connector Type Jack, Female Socket (Concentric)
Contact Termination Solder
Shield Termination Solder Tag
Impedance Non-Constant
Mounting Type Panel Mount
Mounting Feature Bulkhead - Rear Side Nut
Fastening Type Bayonet Lock
Frequency - Max 500 MHz
Number of Ports 1
Features Hermetically Sealed, Three Lug
Housing Color Silver
Center Contact Material Beryllium Copper
Includes 3 pcs - 1 Connector, 1 Nut, 1 Washer
Body Material Stainless Steel
Center Contact Plating Gold
Temperature Range - Operating -65°C ~ 165°C
Voltage Rating 400 V
Mating Cycles 500
Base Product Number BJ77
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4010
Other Names 1097-1034
Standard Package 1
Win Source Part Number 1227600-BJ77HS
Ultra Librarian 3D Model Ultra Librarian BJ77HS CAD Model

Description

The Cinch Connectivity Solutions Trompeter BJ77HS is a hermetically sealed, three-lug coaxial connector designed for jack, female socket (concentric) connection.

  • Connection: Jack, Female Socket (Concentric)
  • Fastening Type: Bayonet Lock
  • Contact Termination: Solder
  • Series: 70
  • Style: TRB Twinaxial/Triaxial
  • Voltage Rating: 400V
  • Frequency Max: 500MHz
  • Material: Stainless Steel
  • Housing Color: Silver
  • Port: One
  • Mounting: Bulkhead-Rear Side Nut
  • Includes: Connector, Nut, Washer (3 pieces)
  • Temperature Range: -65°C to 165°C
  • ECCN: EAR99
  • MSL Level: 1 (unlimited)
  • HTSUS: 69.4010
