3843 Pomona Electronics
Same model may have multiple batches, images only for reference.

3843

Part No 3843
Manufacturer Pomona Electronics
Catalog Coaxial Connectors (RF)
Description CONN ADAPT PLUG TO JACK N 50 OHM
Datasheet
3843 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects - Coaxial Connectors (RF) - Coaxial Connector (RF) Adapters
Mfr Pomona Electronics
Package Bulk
Product Status Active
Adapter Type Plug to Jack
Conversion Type Same Series
Adapter Series N to N
Center Gender Female to Male
Convert From (Adapter End) N Plug, Male Pin
Convert To (Adapter End) N Jack, Female Socket
Impedance 50Ohm
Style Right Angle
Mounting Type Free Hanging (In-Line), Right Angle
Fastening Type Threaded, Threaded
Center Contact Plating Gold
Body Material Brass
Body Finish White Bronze
Center Contact Material Beryllium Copper; Brass
Dielectric Material Polytetrafluoroethylene (PTFE)
Standard Package 2 pcs
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4010
Win Source Part Number 545648-3843
Ultra Librarian 3D Model Ultra Librarian 3843 CAD Model

Description

The 545648-3843 is a coaxial connector adapter designed for use in electronic systems.

  • Fastening Type: Threaded
  • Impedance: 50Ohm
  • Body Material: Brass with white bronze finish
  • Center Contact Material: Beryllium copper and brass with gold plating
  • Conversion: N Plug, Male Pin to N Jack, Female Socket
  • Series: N to N
  • Mounting: Free hanging (in-line) or right angle
