Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Central Semiconductor Corp
Packaging Tube/Rail
Status Active
Transistor Polarity 4 NPN (Quad)
Maximum Current Collector 500mA
VCEO Maximum Collector-Emitter Breakdown Voltage 15V
Max Vce (sat) 250mV @ 1mA, 10mA
Collector Cut-off Current(Max) 400nA (ICBO)
Typical Gain (hFE) (Min) 20 @ 100mA, 2V
Maximum Power Dissipation 500mW
Frequency - Transition 450MHz
Temperature Range - Operating -65°C to 150°C (TJ)
Mounting Through Hole
Case / Package TO-116
Win Source Part Number 044989-MPQ2369
Ultra Librarian 3D Model Ultra Librarian MPQ2369 CAD Model

Description

The MPQ2369 is a quad NPN transistor manufactured by Central Semiconductor Corp. It has a maximum collector-emitter breakdown voltage of 15V and a maximum power dissipation of 500mW.

  • Transistor Type: Quad NPN
  • Maximum Collector-Emitter Breakdown Voltage: 15V
  • Maximum Power Dissipation: 500mW
  • Typical Gain (hFE): 20 @ 100mA 2V
  • Maximum Current Collector: 500mA
  • Maximum Vce (sat): 250mV @ 1mA 10mA
  • Collector Cut-off Current (Max): 400nA (ICBO)
  • Mounting Type: Through-Hole
