2N5460 Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Central Semiconductor Corp
Packaging Bulk
Status Active
Polarity P-Channel
Voltage - Breakdown (V(BR)GSS) 40V
Current - Drain (Idss) @ Vds (Vgs=0) 1mA @ 15V
Voltage - Cutoff (VGS off) @ Id 750mV @ 1μA
Max Input Capacitance 7pF @ 15V
Maximum Power Dissipation 310mW
Temperature Range - Operating -65°C to 150°C (TJ)
Mounting Through Hole
Case / Package TO-92
Win Source Part Number 075339-2N5460
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 2N5460 CAD Model

Description

Product Overview

The 2N5460 JFET is designed for RF amplifier and VHF applications and is known for its remarkable pinch-off voltage and low distortion.

Features and Benefits

  • Low distortion, enhancing signal integrity
  • High input impedance suitable for impedance buffering
  • Operates efficiently at VHF frequencies
  • Robust build for high-reliability circuits

Applications

  • Radio frequency amplifiers
  • VHF tuning systems
  • Impedance matching networks
  • General-purpose amplifier designs

Additional Details: The 2N5460's TO-92 package and standard pin configuration make it easy to handle and implement in various design requirements, featuring a maximum power dissipation of 360 mW.
