PS9634-A CEL PS9634-A Real Image PS9634-A real image
Same model may have multiple batches, images only for reference.
PS9634-A CEL PS9634-A Real Image PS9634-A real image
PS9634-A CEL PS9634-A Real Image PS9634-A real image
Same model may have multiple batches, images only for reference.

PS9634-A

Part No PS9634-A
Manufacturer CEL
Catalog Special Purpose
Description OPTOISO 5KV FOR IGBT DRIVER 8DIP
Datasheet
PS9634-A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer CEL
Packaging Tube/Rail
Status Obsolete(EOL)
Type Power Transistor Driver
Number of Channels 1
Isolation Voltage 5000Vrms
Common Mode Transient Immunity (Min) 1kV/μs
Input Type DC
Channel Output Current 500mA, 800mA
Propagation Delay tpLH / tpHL (Max) 5μs, 5μs
Forward Voltage 1.1V
Continuous forward current- Max 30mA
Supply Voltage - Operating 5.4 V to 15 V
Temperature Range - Operating -20°C to 80°C
Mounting Through Hole
Case / Package 8-DIP
Win Source Part Number 1090252-PS9634-A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian PS9634-A CAD Model

Description

The PS9634-A is a power transistor driver type that is mounted through a hole manufactured by CEL.

  • Forward Voltage: 1.1V
  • Input Type: DC
  • Channels: 1
  • Common Mode Transient Immunity: 1kV/μs
  • Propagation Delay tpLH / tpHL: 5μs and 5μs respectively
  • Isolation Voltage: 5000Vrms
  • Temperature Range: -20°C to 80°C
