PS2805-4 NEC PS2805-4 Real Image PS2805-4 real image 2 PS2805-4 real image12985
Same model may have multiple batches, images only for reference.
PS2805-4 NEC PS2805-4 Real Image PS2805-4 real image 2 PS2805-4 real image12985
PS2805-4 NEC PS2805-4 Real Image PS2805-4 real image 2 PS2805-4 real image12985
Same model may have multiple batches, images only for reference.

PS2805-4

Part No PS2805-4
Manufacturer CEL
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 2.5KV 4CH TRANS 16SOIC
Datasheet
PS2805-4 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Isolators - Optoisolators - Transistor, Photovoltaic Output Optoisolators
Mfr CEL
Series NEPOC
Package Tube
Product Status Obsolete
Number of Channels 4
Voltage - Isolation 2500Vrms
Current Transfer Ratio (Min) 80% @ 5mA
Current Transfer Ratio (Max) 600% @ 5mA
Rise / Fall Time (Typ) 3µs, 5µs
Input Type AC, DC
Output Type Transistor
Voltage - Output (Max) 80V
Current - Output / Channel 50mA
Voltage - Forward (Vf) (Typ) 1.1V
Current - DC Forward (If) (Max) 50 mA
Vce Saturation (Max) 300mV
Temperature Range - Operating -55°C ~ 100°C
Mounting Type Surface Mount
Package / Case 16-SOIC (0.173", 4.40mm Width)
Standard Package 45 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8541.49.8000
Win Source Part Number 656964-PS2805-4
Ultra Librarian 3D Model Ultra Librarian PS2805-4 CAD Model

Description

The PS2805-4 is an optoisolator from the NEPOC series by CEL.

  • Current Transfer Ratio (Min): 80% @ 5mA
  • Voltage - Isolation: 2500Vrms
  • Output Type: Transistor
  • Current - Output / Channel: 50mA
  • Number of Channels: 4
  • Mounting Type: Surface Mount
  • Package / Case: 16-SOIC
  • Voltage - Output (Max): 80V
  • Vce Saturation (Max): 300mV
  • Product Status: Obsolete
