The SST502 is a JFET current source manufactured by Calogic, LLC. This device provides a stable and predictable current over a wide voltage range, making it suitable for applications requiring a constant current source. The SST502 is designed for precision current regulation in various electronic circuits.
Applications:
- LED driving
- Analog circuit biasing
- Sensor excitation
- Current limiters
- Voltage references
Features:
- JFET Current Source
- Fixed current output
- Wide voltage range
- High output impedance
- Low temperature coefficient
- RoHS compliant
Benefits:
- Stable and predictable current source
- Simplified circuit design
- Improved circuit performance
- Reduced component count
- Environmentally friendly
Additional Details:
The SST502 provides a fixed current output that is relatively independent of variations in supply voltage and temperature. This makes it ideal for applications where a stable current source is required. The high output impedance ensures that the current remains constant even with changes in the load. The low temperature coefficient minimizes the effect of temperature variations on the output current. The device is typically available in a through-hole or surface-mount package. Refer to the datasheet for detailed specifications, including the nominal current, voltage range, and temperature characteristics. Calogic emphasizes the SST502's precision and reliability in current regulation applications.
