MGA-30689-TR1G Real Image MGA-30689-TR1G label picture MGA-30689-TR1G real image
Same model may have multiple batches, images only for reference.
MGA-30689-TR1G Real Image MGA-30689-TR1G label picture MGA-30689-TR1G real image
MGA-30689-TR1G Real Image MGA-30689-TR1G label picture MGA-30689-TR1G real image
Same model may have multiple batches, images only for reference.

MGA-30689-TR1G

Part No MGA-30689-TR1G
Manufacturer Broadcom Limited
Catalog RF Amplifiers
Description IC GAIN BLOCK 40DBM LN SOT-89
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Frequency 40MHz to 2.6GHz
P1dB 22.5dBm
Gain 14.6dB
Noise Figure 3.3dB
RF Type General Purpose
Supply Voltage - Operating 5V
Operating Supply Current 104mA
Test Frequency 1.95GHz
Case / Package SOT-89-3
Win Source Part Number 058475-MGA-30689-TR1G
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian MGA-30689-TR1G CAD Model

Description

The Broadcom Limited MGA-30689-TR1G is a general-purpose RF amplifier with a frequency range of 40MHz to 2.6GHz.

  • Gain: 14.6dB
  • Noise Figure: 3.3dB
  • P1dB: 22.5dBm
  • Supply Voltage: 5V
  • Operating Supply Current: 104mA
  • Supply and Demand Status: Limited
  • Quantity per Package: 3k pcs
  • Alternative Parts: HMC636ST89E, SKY65045-70LF, and MGA-30689
